PM24 Cat M1 - LTE Alarm Communicator

Select Variant
PM24 Cat M1 - LTE Alarm Communicator

PM24 Cat M1 - LTE Alarm Communicator

Available:
AU | NZ
Download
Spec Sheet

The PM24 is the most compact and cost-effective way to achieve a constant secure link between a supervised premises and its control room. Developed to deliver optimum efficiency, it features extended range for superior building penetration while using minimal power from the alarm panel.

Video

Video

key features
Leverages the latest 4G/5G CAT M1 network designed for machine-to-machine comms.

Fast and easy plug-and-play installation and integration.

Attaches to the alarm panel with magnets so no drilling is required.

Remote monitoring and management through Atlas software from Permaconn.

On-the-go monitoring and management with the Pocket Secure mobile app from Permaconn.

Specifications

Housing Material:

ABS plastic - Green

Dimensions:

108mm (H) x 15.5mm (D) 80mm (W)

Weight:

80g

Cat :

M1

LTE FDD:

B3 / B28

Modem:

Quectel BG96

Power:

8–15V DC Terminal Supply

Power Consumption:

Standby: 0.04A @13.8v DC, Transmitting: 0.19A @13.8v DC

Auxiliary Input:

3x 24hr inputs – state change Detected every second EOL 3.3K

Auxiliary Output:

3x Open Collector outputs @ 50mA (max)

Function:

Control using Atlas web portal and/or “Pocket Secure” App

Data Security:

AES128 Encryption

Approvals:

EN62311: 2008, AS/NZS 2772.2: 2016, AS/NZS 60950.1:2015
AS/NZS CISPR 22: 2009+A1: 2010
AS/CA S042.4: 2015, AS/NZS 60950.1:2015
EN 55032: 2015, EN 55024: 2010+A1:2015
EN 61000-3-2: 2014, EN 61000-3-3: 2013
ETSI EN 301 489-1 V 2.1.1 (2017-02)
Draft ETSI EN 301 489-52 V1.1.0 (2016-11)
ETSI EN 301 908-1 V11.1.1(2016-07)
ETSI EN 301 908-2 V11.1.1(2016-07)
ETSI EN 301 908-1 V11.1.1 (2016-07)
ETSI EN 301 908-13 V11.1.1 (2016-07), EN62479: 2010
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
